Product Name: |
Stainless Steel Pressure Gauge |
|
Normal Size: |
2.5"(63mm),4"(100mm),6"(150mm). |
|
Pressure Range: |
-1Bar(-30"Hg)-0-1000Bar(15000Psi) |
|
Accuracy: |
±1%,±1.6% |
|
Operating temperature: |
-20°C to +60°C |
|
Case: |
Stainless steel |
|
Bezel: |
Stainless steel |
|
Bourdon tube: |
Copper alloy or Stainless steel <100Bar: C-Type ≥100Bar: Helical Type |
|
Connection: |
304 or 316 Stainless steel |
|
Movement: |
316 Stainless steel |
|
Dial: |
Aluminum |
|
Pointer: |
Aluminum |
|
Window: |
Safety or Tempered Glass |
|
Thread: |
1/8",1/4", 3/8",1/2"; PT(BSPT,ZG),BSP(G,PF),NPT etc. |
|
Liquid: |
Glycerin or Silicone |
|
Gaskets Filling cap: |
Nitrile or Silica gel |
